Resources for the Repair and Maintenance of your Honda Pilot
Honda Pilot Models:
Honda Pilot Problems
Vibration When Braking Due to Rotor Problem
The front brake rotors can warp and cause a vibration when braking. The rotors will need to be machined or in cases where they are worn to thin, replaced to correct this issue.
Water Leak Due to Poor Seal at Side Marker Wire Harness
On certain models a leaking side marker light wire harness can cause a water leak inside the vehicle. Resealing the wire harness where it goes through the body into the cabin area should stop the leak.
Noise and Judder on Turns From Rear Axle
Noise and judder can develop from the rear axle due to differential fluid breakdown. Replacing the fluid will commonly correct this issue.
Low Beams Not Working Due to Poor Connection at Combination Switch
An overheated wire in the head light harness can cause the low beams not to work. Replacing combination light/turn signal switch switch, the wire for the low beams, and the combination switch connector (if damaged) should repair this issue.
Shim to Correct Chirping Timing Belt
A chirp noise from the timing belt area can be caused by a tilted idler pulley. Installing a corrective shim from Honda will commonly correct this issue.
Honda Pilot Recalls (Recent)
Honda and Acura Recall Multiple Vehicles Due to Excessive Air Bag Inflator Pressure
RepairPal Expert Overview:
Honda has recalled 2001-2003 Civic, 2002-2003 Civic SI, 2001-2002 Accord, 2002 CR-V, 2002 Odyssey, 2003 Pilot, 2002-2003 Acura TL, and 2003 Acura CL vehicles because the driver's side air bag inflator may produce excessive internal pressure. This could cause the inflator to rupture if the air bag deploys. Metal fragments may pass through the air bag material and cause injury to vehicle occupants. Dealers will replace the driver's side air bag inflator.
Learn more »Honda Recalls 2006-2007 Models Due to Incorrect NHTSA Contact Information in Owner's Manual
RepairPal Expert Overview:
Honda has recalled 2006 Accord, Civic, CR-V, Element, Insight, Odyssey, Pilot, Ridgeline, Acura MDX, RL, RSX, TL, TSX, and 2007 Honda Fit vehicles because the contact information for the National Highway Traffic Safety Administration (NHTSA) is listed incorrectly in the owner's manual. Honda is contacting dealers and customers to provide them with a postcard containing the correct information.
Learn more »One or Both Seatbelts May Detach from Their Anchors
RepairPal Expert Overview:
The stitching that secures the end of the lap section of the driver and front passenger seatbelt may be incomplete or missing. As a result, the seatbelt may detach from the anchor webbing, increasing the risk of personal injury in a crash. Dealers will inspect and replace the affected seatbelts as necessary. The Honda recall number is R95.
Learn more »Low Beam Headlights May Fail
RepairPal Expert Overview:
The electrical terminal for the low beam headlights may wear in the electrical connecter at the combination headlight switch. This can cause increased electrical resistance and melting of the terminal ends within the wiring harness connector. Failure of the electrical connector can cause the low beam headlights to become inoperative, reducing driver visibility and increasing the risk of a crash. Dealers will repair the damaged terminal harness or replace the combination lighting switch as necessary to correct this concern. The Honda recall number is S34.
Learn more »Potential Fuel Leak
RepairPal Expert Overview:
The vent shut float (VSF) valve case in the fuel tank assembly does not meet design specifications. As a result, fuel may leak from the fuel tank, increasing the risk of a fire. Dealers will inspect the VSF assembly date, and if necessary, replace the fuel tank assembly to correct this concern. The Honda recall numbers are S25 and S26.
Learn more »Honda Pilot Questions and Answers
how do i repair it
what do you need to get checked on the 150,000 mile check up and how much should it cost
What is induction or injection service? What is a throttle body?
I'm trying to clean the valve. Can't find exact position. Do I need to take of the silver oblong cover. The one with allen wrenches?
What should expcet to pay to have my timing belt and water pump replace (including [parts and labour)?
Honda Pilot Stories
I bought my 2003 EXL with 95K on it. I have had to replace almost every suspension part including ball joints. All that being said it drives and operates nicely in the winter. There is a severe vibration noise coming from the rear of the vehicle that sounds like going over bump strips. It actually slows the vehicle down. Maybe differential clutches or ?? Any thoughts?
Even though I park my Pilot in the garage every night, each morning I have a low tire pressure light on at least one tire sometimes two.I am really getting tired of checking air pressure and pumping air on these cold Ohio mornings. What can I do?
I've owned (2) 2003 Honda Pilots. Bought first Pilot EX-L in late 2002. I had it until it was totaled by a kid running a red light in July 2010. (154K miles). Very reliable vehicle. I had no major repairs that weren't part of regular maintenance. With the insurance money + $1500, i was able to purchase a 2003 Pilot EX in August 2010 (96K miles). Previous owner maintained vehicle better than I did mine. I've put 23K miles on it; no problems, reliable as expected.
If you are able to pay for the regular maintenance schedule (15K), the Pilot should last for years after it has been paid for.
I have a 2003 pilot when the ignition is on and in park the P as in park light will come on as uaual but now the D as in drive light will come on as well when put into amy gear the light will go off. Is this a major problem.
Bought the 07 new. 2 wheel drive with ECO-DRIVE. Good car but the gas mileage has never been close to what they said. I check the mileage every tankful and usually get 17.2 in the city and 19 on the highway. Not the 19 & 22 on the sticker.
