1994 Mazda Navajo Problems

Crank but No Start Condition and No Fuel Pressure

If the engine cranks but does not start, it may be caused by a tripped inertia switch. Switch the key to "ON" and the fuel pump should be heard running for a second or two. Listen at the gas filler if necessary. The inertia switch is located on the firewall and can be tripped when the parking brake is set too hard and then released. The inertia switch should be reset, and will click when it is reset.

Power Steering Pump/Gearbox Problems Due to Fluid Contamination

Failure to change the power steering fluid can cause the fluid to become gray with metal particles. The contaminated fluid can damage the power steering pump resulting in a growling noise when the wheel is turned; the damaged pump will require replacement to eliminate the noise.. Life of the power steering gearbox and pump will be shortened if the fluid is not serviced regularly.

AC Not Cold Due to Refrigerant Loss

The O-ring seals in the AC couplings can develop leaks. The condenser can also crack and leak, which is sometimes misdiagnosed as a leaking coupling.  The condenser cracks out of sight, under the radiator support, so it looks like the coupler is leaking. Leak testing with fluorescent dye will help locate the exact source of the leak.

See More Problems (6)

1994 Mazda Navajo Questions

Engine light maf sensor bad, replaced now car goes into limp mode when on (1 answer)

Before new sensor car ran great light was driving me crazy now if maf sensor on it runs rich n cuts out take sensor off n it idles n runs fine again I'm on 292nd mechanic that does not have a clue codes only read maf sensor what to do

Why don't I have any spark when trying to start my truck? (1 answer)

I just replaced fuel pump and found that there was wire shortage somewhere in my fuse panel. (haven't found where.) replaced the fuse that blew (EEC power) and was driving down the road and my truck shut off. Checked the fuse that blew and it was fine but truck wont star. Turn the key and you...

Soft brake pedal (1 answer)

Replaced Master cylinder (2 times), Vaccuum booster, calipers, rotors, pads, wheel cylinders, drums and shoes. Had HCU bled at ford dealership. pressure bled system 2 times, still pedal sinks to floor. If pumped will build pressure. Soft application will sink to floor. HELP

See More Questions (11)

1994 Mazda Navajo Recalls

Ford Recalls Firestone Wilderness AT and Radial ATX Tires on Multiple Trucks and SUVs

Ford has recalled Firestone Wilderness AT and Radial ATX tires installed on multiple lines of Ford trucks from 1991 to 2000. On some tires, under extreme conditions, the tread could separate, which can cause immediate tire failure. This may lead to a loss of vehicle control, injury, and death. Dealers replaced the affected tires.

Recall 99V310002
VEHICLE DESCRIPTION: ON CERTAIN SPORT UTILITY VEHICLES, THE HYDRAULIC LIFT CYLINDER BRACKET WELDS COULD FRACTURE.
Recall 96V024002
THE STUDS WHICH ATTACH THE BRAKE MASTER CYLINDER TO THE POWER BRAKE VACUUM BOOSTER ASSEMBLY CAN DEVELOP STRESS CORROSION CRACKING AFTER BEING OPERATED FOR AN EXTENDED PERIOD OF TIME IN THE SOUTHERN CALIFORNIA LOCATION.

See More Recalls (4)

1994 Mazda Navajo Reviews

Rated
based on 1 customer reviews
I have a 94 Navajo , and so far besides the minor repairs i did when first purchased it , such as wipers, all major fluids ( all 3 gearboxes, tarnsmission, and oil, and so forth) , so far only things that have gone wrong were i had to replace both front shocks( went with heavy duty offroad shocks for the way i drive in city streets :) ) DS radius arm bushing , only prioblems i have are temp g...
