» » » 1993

Resources for the Repair and Maintenance of your 1993 Mazda Navajo

1993 Mazda Navajo

Image for car images Mazda 1991 1994 Mazda Navajo size thumb

1993 Mazda Navajo Problems

Engine -- Verified

If the engine cranks but does not start, it may be caused by a tripped inertia switch. Switch the key to "ON" and the fuel pump should be heard running for a second or two. Listen at the gas filler if necessary. The inertia switch is located on the firewall and can be tripped when the parking brake is set too hard and then released. The inertia switch should be reset, and will click when it is reset.

Engine -- Verified

If the engine stalls when coming to a stop and/or has a rough idle, it may be due to sludge accumulation in the throttle body and idle air control valve. The throttle body and idle air control valve will need to be cleaned if there is buildup.

Engine -- RepairPal and 3 others

Suspension & Steering -- Verified

Failure to change the power steering fluid can cause the fluid to become gray with metal particles. The contaminated fluid can damage the power steering pump resulting in a growling noise when the wheel is turned; the damaged pump will require replacement to eliminate the noise.. Life of the power steering gearbox and pump will be shortened if the fluid is not serviced regularly.

Suspension & Steering -- Verified

The radius arm bushing may wear, causing a clunking or popping noise when driving over bumps. To repair, the bushings need to be replaced. Depending on the severity of the wear, the brackets may also need replacement. Driving with worn bushings will shorten tire life and cause tire cupping (uneven tire wear).

1993 Mazda Navajo Recalls (Recent)

Body, Interior & Misc., December 1, 1995

Summary: THE HYDRAULIC LIFT CYLINDERS ARE ATTACHED TO BRACKETS THAT ARE WELDED TO THE LIFTGATE. THE BRACKET WELDS CAN FRACTURE.

Learn more »

Body, Interior & Misc., July 16, 1998

Summary: VEHICLE DESCRIPTION: MULTI-PURPOSE PASSENGER VEHICLES EQUIPPED WITH FACTORY INSTALLED SUNROOF. THE SUNROOF GLASS PANEL ASSEMBLY CAN SEPARATE WHILE THE VEHICLE IS MOVING DUE TO INCORRECT HINGE ENGAGEMENT. THIS WAS CAUSED BY IMPROPER SUNROOF INSTALLATION OF THE GLASS PANEL.

Learn more »

Brakes, November 4, 1994

Summary: THE PARKING BRAKE CONTROL SELF-ADJUST PAWL DOES NOT LINE UP PROPERLY WITH THE SELF-ADJUST RACHET CAUSING THE PAWL TO SLIP OVER ONE OR MORE TEETH IN THE RACHET.

Learn more »

Brakes, May 21, 1996

Summary: THE STUDS WHICH ATTACH THE BRAKE MASTER CYLINDER TO THE POWER BRAKE VACUUM BOOSTER ASSEMBLY CAN DEVELOP STRESS CORROSION CRACKING AFTER BEING OPERATED FOR AN EXTENDED PERIOD OF TIME IN THE SOUTHERN CALIFORNIA LOCATION.

Learn more »

Drive Train, August 26, 2000

RepairPal Expert Overview:

Ford has recalled Firestone Wilderness AT and Radial ATX tires installed on multiple lines of Ford trucks from 1991 to 2000. On some tires, under extreme conditions, the tread could separate, which can cause immediate tire failure. This may lead to a loss of vehicle control, injury, and death. Dealers replaced the affected tires.

Learn more »

1993 Mazda Navajo Questions and Answers

Visitor, 1993 Mazda Navajo, West Fargo, ND

where is the inertia switch

samsmom, 1993 Mazda Navajo, Oklahoma City, OK

heater does not blow warm or hot only cold

Visitor, 1993 Mazda Navajo, Wichita Falls, TX

Where is the fuel pump reset button or inerta shut off switch on a 1993 Mazda Navajo?

jerrycruthis, 1993 Mazda Navajo, Mexia, TX

ive replaced clutch and slave cylinder and it pumps up about 1/2 way i understand there is a adjustment on the clutch master cylinder help mew find that adjustment

terry1963, 1993 Mazda Navajo, Armuchee, GA

I replaced the blown motor but I need the exact specs for the vacum hoses.

Write a Review About Your Car

1993 Mazda Navajo Reviews

Great little 4X4 gas mileage stink buy became better with a K and N filter ... I had the same engine in a Ford ranger truck and got much better gas mileage ... the one I have has just 51000 miles and its a 93 .... any suggestions on getting better mileage ????
