Resources for the Repair and Maintenance of your Mazda B4000
Mazda B4000 Models:
Mazda B4000 Problems
Crank but No Start Condition and No Fuel Pressure
If the engine cranks but does not start, it may be caused by a tripped inertia switch. Switch the key to "ON" and the fuel pump should be heard running for a second or two. Listen at the gas filler if necessary. The inertia switch is located on the firewall and can be tripped when the parking brake is set too hard and then released. The inertia switch should be reset, and will click when it is reset.
Runs Poorly, Possible Check Engine Light
A dirty, or contaminated mass airflow sensor (MAF) can cause the engine to run poorly. The Check Engine Light may or may not illuminate. MAF sensor related fault codes P0102 and/or P0103 may be stored. In some cases, carefully cleaning the sensor element will fix the problem. If not, replacement of the sensor may be required.
Crank but No Start Condition and No Spark
The engine may fail to start due to an electrically shorted sensor. Some of the sensors may internally short and not blow any fuses. A technician may find no spark and no operation of the fuel injectors in the diagnosis. One way a technician may isolate the defective sensor is by disconnecting sensors one by one to see if the engine starts.
Rough Running Idle, Erratic Speedometer Operation, ABS Light Illuminated, Check Engine Light, and Automatic Transmission Shifting Problems
Water intrusion into a connector (X309) located under the cab, beneath the driver's seat, can cause a rough idle, erratic speedometer operation, ABS Light and Check Engine Light illumination, and automatic transmission shifting problems. If needed, connector repair parts are available from Mazda dealers, and possibly some Ford dealers.
Mazda B4000 Recalls (Recent)
Mazda B2500 Recall 01V227002
Summary: VEHICLE DESCRIPTION: LIGHT DUTY TRUCKS EQUIPPED WITH SEAT BELTS SUPPLIED BY TRW. IT IS POSSIBLE THAT THE DRIVER'S AND/OR FRONT PASSENGER'S OUTBOARD SEAT BELT BUCKLE MAY NOT FULLY LATCH. FORD CROWN VICTORIA BUILT AT ST. THOMAS ASSEMBLY PLANT FROM 4/17/00 - 5/29/01 MERCURY GRAND MARQUIS BUILT AT ST. THOMAS ASSEMBLY PLANT FROM 4/17/00 - 5/29/01. LINCOLN TOWN CARS BUILT AT WIXOM ASSEMBLY PLANT FROM 3/27/00 - 5/30/01. LINCOLN NAVIGATORS BUILT AT MICHIGAN TRUCK PLANT FROM 4/11/00 - 5/31/01. FORD WINDSTARS BUILT AT OAKVILLE ASSEMBLY PLANT FROM 3/23/00 - 5/30/01. FORD RANGERS BUILT AT TWIN CITIES PLANT FROM 3/28/00 - 5/30/01, AND ALSO AT THE EDISON PLANT FROM 3/13/00 - 5/25/01. FORD F-150 TRUCK BUILT AT NORFOLK PLANT FROM 4/18/00 - 5/25/00; AT ONTARIO PLANT FROM 5/10/00 - 5/28/01; AT KANSAS CITY PLANT FROM 9/11/99 - 5/25/01; AND AT CUAUTITLAN PLANT FROM 5/16/00 - 6/9/01. FORD SUPER DUTY F-250, F-350, F-450, AND F-550 TRUCKS BUILT AT KENTUCKY PLANT FROM 4/17/00 - 5/27/01; AND AT CUAUTITLAN PLANT FROM 5/16/00 - 6/19/01. FORD EXCURSIONS BUILT AT KENTUCKY PLANT FROM 4/17/00 - 10/2/00. FORD EXPEDITIONS BUILT AT MICHIGAN TRUCK PLANT FROM 4/11/00 - 5/31/01.
Learn more »Windshield Motor May Fail
RepairPal Expert Overview:
The windshield wiper may have been produced without grease applied to the output shaft gear. After a period of continuous use on the high speed setting, this lack of grease could cause the gear teeth to distort or fracture resulting in the loss of wiper function. An inoperative wiper during inclement weather conditions could cause a crash due to impaired visibility. Dealers will inspect the wiper motor for the presence of grease. Grease will be applied to the wiper motor gears if necessary. The Mazda recall number is 3705K.
Learn more »
Mazda B2500 Recall 07V347000
Summary: ON CERTAIN TRUCKS EQUIPPED WITH A SPEED CONTROL SYSTEM, THE SPEED CONTROL DEACTIVATION SWITCH MAY, UNDER CERTAIN CONDITIONS, LEAK INTERNALLY AND THEN OVERHEAT, SMOKE, OR BURN.
Learn more »Mazda B2500 Recall 09V414000
Summary: MAZDA IS RECALLING MODEL YEAR 1995 THROUGH 1997 AND MODEL YEAR 2001 THROUGH 2003 TRUCKS EQUIPPED WITH TEXAS INSTRUMENTS SPEED CONTROL DEACTIVATION SWITCH (SCDS) AND/OR ANTI-LOCK BRAKE SYSTEM (ABS) AND MANUFACTURED ON OR BEFORE DECEMBER 5, 2002. A COMPONENT OF THE CRUISE CONTROL DEACTIVATION SWITCH MAY DETERIORATE OVER TIME AND DEVELOP A LEAK. THIS OCCURRENCE COULD CAUSE THE SWITCH TO OVERHEAT, SMOKE OR BURN WHICH COULD RESULT IN AN UNDER HOOD FIRE.
Learn more »Wheel May Separate from the Axle
RepairPal Expert Overview:
The front spindle stem may crack due to a manufacturing defect. If the spindle stem fractures, the wheel may come off the axle. Steering may be compromised, increasing the risk of a crash. The recall began on February 9, 2009. The Mazda recall number is 5109A.
Learn more »Mazda B4000 Questions and Answers
where is oil sending unit location
what size is this hose
does this estimate include the price of having the the head checked at a machine shop
I have a B4000 SE with 4 wheel drive. When I turn the wheel too the right I hear a "gear meshing" noise, as if the 4 wheel drive is trying to engage? If I engage the 4 wheel drive the noise stops? ...
Both the ABS light and the BRAKE warning lights are illuminated on the dash on my truck, with no apparent reason, and no other symptoms (brakes work fine). Rotors, calipers etc. all replaced 6 mont...
Mazda B4000 Stories
I love me truck. However recently it stallesd, I had to wait 5-10 min for it to restart. Thought it was the cadiledic converter as it ran rough and the exhaust was red. Now it doesn't start when it is hot. Have replaced the oxygen sensors,the ECT sensor, ignition moduale, TPS, and the feul filter. After the feul filter replacement the truck randomly chugs whe going down the road. Still won't start when hot. I am lost but still love my truck
Bought this truck used and it has over 140,000 miles and has been great. recently rubber went bad in front say bars. Dont know if thats a hard problem to fix. anyone had to do it. Does it require alot of work.
Other than that. LOVE MY Truck.
if your transfercase motor goes out. dont by another one. i can give u an easy fix.... and it ony takes 30mins r less 2 fix.
Bought truck with 120,000 miles love it runs great need new paint job clear coat came off. The best truck Mazda ever built best motor in this truck 4.0 v6.
My truck I bought used and is great. It has problem on certian days when it's cold and raining. The truck will crank and try to start but can't. If you have any info about what might be happening please email me at luke.trahan@yahoo.com.
Thank You.
