2004 Volvo XC90 Repair and Maintenance

A guide to problems, costs, maintenance and repair for your 2004 Volvo XC90

2004 Volvo XC90 Problems

Engine will not start - Electronic Control Module problem.

On several occasions the car would not start. When the key was turned nothing would happen. Car was towed 3 times. First time they stated it was the starter motor. Second time new battery. Third time it was the electronic control module that needed replacememt. A common problem as I under. I believe that all 3 times it was the ECM. Water leakage can get into the unit via a poorly designed rubber grommet (seal). Only the Volvo dealerhip c...

Transmission Failure Common

Premature automatic transmission failure is common. Diagnoses of the fault will be necessary to determine if repair or replacement is the proper repair.

Hard Shifting, Erratic Shifting and Other Transmission Issues

Many complaints have been reported regarding Volvo XC90 transmission shifting issues. Long shift times between gear shifts, hard shifting, hard downshifting and a loss of transmission operation all together to name a few.

If the issue is minor, a transmission software update may address this issue so if available, the software should be updated before any repairs are made. After a software update or repair, the shift adaptation needs to be reset. A good quality Volvo repair shop will know how to perform this task.

There are several technical service bulletins (TSB's) available from Volvo that address these shifting issues and they should be consulted by the repair shop during the automatic transmission diagnostic process.

Regular servicing of the transmission fluid can help with preventing transmission failure, but not in all cases. Follow the suggested fluid replacement interval recommended by Volvo. You will find this in your owners manual, or find it here: http://bit.ly/Volvo_Owners_Manuals

See More Problems (7)

2004 Volvo XC90 Questions

How much should a fuel pump replacement cost (on average) for a 2004 XC90 AWD? (1 answer)

Washington State (Puget Sound Area)

What strut mounts, struts, and bumpers do I need for my vehicle. Part #'s please (2 answers)

I'm unable to locate the exact part numbers for my vehicle

Why is my coolant boiling in the reservoir And my car isn't over heating? (1 answer)

I have a 2004 Volvo XC90 turbo. The first sign was low coolant. I checked and it was boiling. Then before I could get home it said low coolant stop engine. Again I checked, it was boiling. Then the antifreeze starts leaking and I was told the radiator had a small hole in it. Now my car never over...

See More Questions (81)

2004 Volvo XC90 Recalls

Volvo Recalls Garmin 760 Portable GPS-Equipped Vehicles Due to Overheating Battery

Volvo is recalling all models equipped with Garmin 760 Portable Global Positioning System units because the battery may overheat, which could lead to a fire. Volvo advises owners to stop using the Garmin device immediately and consult the Garmin website to determine if they have a defective unit. The unit's battery will be replaced and a spacer inserted to prevent the problem from reoccurring. This will be performed free of charge.

Vehicles in Warm Weather Climates May Develop a Fuel Leak

When exposed to certain environmental conditions (hot climate and temperature cycling) over time and in combination with varying fuel quality, the fuel pump can develop cracks in the fuel pump flange. If cracks develop, a fuel smell and/or leak may be noted. Any fuel leak always increases the risk of a fire. Dealers will inspect and replace the fuel pump as necessary to correct this concern. The Volvo recall number is R220.

The Windshield Wipers May Fail in Extreme Winter Weather Conditions

If the windshield wipers are activated in extreme winter weather conditions and without lifting the wiper arms and cleaning the windshield prior to moving, the wiper arm can slip on its driveshaft, resulting in an inability to move the wipers from the park position. Inoperative wipers during inclement weather conditions could cause a crash due to reduced visibility. Dealers will replace the wiper arms and retaining nuts to correct this concern. The Volvo recall number is R156.



See More Recalls (6)

2004 Volvo XC90 Reviews

We bought it new in 03. We have 165K miles on it. All service done in Dedham, Mass. Its been a great car. I am planning on getting at least 250K on it. All repairs, service, tires, brakes, exhaust, everything averaged about $1200 per year. I am happy. Can't wait for the new XC90 PHEV. I own 2 other Volvo's and our experience has been the same on both. The Dealer makes a lot of diffe...
Volvo has lost it's way. Our 2004 xc90 turbo has been the least reliable of any car we have owned. What is more concerning is the lack of response from Volvo Service. The reported 'safety' of this brand is exaggerated, for example the vehicle would 'shut down' to 1/4 power while on highway with no dashboard, signals etc. Each time it was towed to service and supposedly fixed (battery, and many ...
I bought my XC90 (T6 AWD) used with 71k back in 2009 when I moved-back from the UK to the US. Overseas, XC90 is an amazing vehicle. In the US, so-so. I was in a crunch and got a decent deal for it. And, I bought a 3-yr/36k extended warranty. Good thing! I've had enough repairs done to cover the cost of the warranty 3-times plus. But, the car works great. Its not what I wanted but its ex...

See More Reviews (9)
