2013 Volkswagen Eos Repair and Maintenance

A guide to problems, costs, maintenance and repair for your 2013 Volkswagen Eos

2013 Volkswagen Eos Problems

Check Engine Light and/or Hesitation Due to Failed High Pressure Fuel Pump

2.0L turbo charged engines may develop a hesitation on acceleration and/or illumination of the Check Engine Light due to a failed high pressure fuel pump or a worn camshaft follower or camshaft. To help prevent this issue from occurring, the cam follower should be inspected every 10,000 - 15,000 miles. The camshaft lobe pushes on the follower to operate the high pressure fuel pump.

To correct this issue one or all of the following will need replacement: the camshaft, high-pressure fuel pump, and/or the cam follower.



Decreased Power and Fuel Economy from Carbon Buildup

The Volkswagen Eos uses the FSI and TSI direct injection engines. These engines are subject to carbon buildup in the intake system which can cause power loss, OBD codes and a check engine light, and a rough idle. In normal engines, the engine is cleaned by the gasoline flowing through the injectors and into the intake system, however, since the Eos uses direct injection, gasoline does not flow through common carbon buildup areas.

 Possible trouble codes include: P0300P0301P0302P0303P0304.

The solution is to remove the intake manifold and professionally clean the intake manifold, intake ports on the cylinder head, and the intake valves. This may need to be done in as few as 20,000 miles.

No Start after Refueling and Popping Noise from Trunk

Popping sounds from the rear of the vehicle may be heard moments after starting the engine, or when slowing to a stop. This noise is from the leak detection pump filling the fuel tank with air, and releasing to retest the system when it finds a fault. The sequence of faults identifying this issue are as follows:

  • Succession of loud pops from rear of vehicle
  • Pops go away, and fuel economy decreases
  • Check engine light illuminates
  • OBD trouble code P2404 and/or P0441 is stored
  • Engine will not start after refueling (must crank for over 30 seconds)
  • Vibration when slowing to a stop

The cause is a valve which is mounted on the front of the intake manifold, commonly called the N80 valve, or EVAP system purge valve. The valve is designed to open under specific circumstances, but a worn valve will remain open at all times, preventing the pressurization of the fuel tank.

Correction of the issue is to replace the N80 valve with the latest revision.

See More Problems (3)

2013 Volkswagen Eos Questions

Do you have to manually turn your headlights on and off? (1 answer)

It's been a long time since I had a car that you had to turn the headlights off manually. What's up with this.

See More Questions (2)

2013 Volkswagen Eos Recalls

Driver's Frontal Air Bag Inflator Ruptures And Sprays Metal Fragments

The driver's frontal air bag inflator may deploy the air bag with excessive pressure, resulting in the inflator rupturing and causing metal debris to be sprayed onto vehicle occupants. Dealers will replace the driver's frontal air bag inflator free of charge to resolve the concern.

Drivers Side Air Bag Does Not Function In Crash

The driver's side air bag may not be powered due to a loss of electrical connection from the clock spring sliding contact in the steering wheel caused by contamination. Dealers will repair the vehicle free of charge.

See More Recalls (2)
