2006 Toyota RAV4 Repair and Maintenance

A guide to problems, costs, maintenance and repair for your 2006 Toyota RAV4

No_car_image
Get a Repair Estimate
Guaranteed by certified locations nationwide. Learn more
Get a Repair Estimate For Your 2006 Toyota RAV4
RepairPal estimates are guaranteed at over 1,700 quality certified locations nationwide. Learn more
Repair Estimates

Never overpay. Check prices with our estimator

2006 Toyota RAV4
$
383
to $
1,026
2006 Toyota RAV4
$
221
to $
945
2006 Toyota RAV4
$
138
to $
298
2006 Toyota RAV4
$
1,214
to $
4,217
2006 Toyota RAV4
$
412
to $
593

2006 Toyota RAV4 Problems

Rough Running Conditions and Smoke From Exhaust

The head gasket may fail due to a defect in manufacturing of the cylinder block.

On this vehicle, the head bolts are known to pull the threads out of the engine block, allowing the head to slightly lift, and causing head gasket failure. Symptoms may include:

  • Overheating
  • White smoke from exhaust
  • Rough running conditions and/or inability to start or idle
  • White or cream colored oil on dipstick
  • Check engine light
  • OBD Trouble Codes P2181, P0300

When the head gasket fails, the bolt holes for the head bolts must be repaired before the cylinder head can be remounted.

This issue is not always preventable, but to help avoid it, never run the engine if the engine temperature is ever above the normal range.

Excessive Oil Consumption

Drivers of the Toyota RAV4 may notice excessive oil consumption between oil changes, even to the extent of the engine oil warning light displayed on the multi-function display.

This issue is known to be caused by infrequent oil changes causing engine sludge, or worn piston rings.

The engine should be cleaned of oil sludge, and if oil consumption remains excessive, the engine may need new piston rings, or other internal components replaced.

To avoid this issue, change the engine oil and filter every 3,000 miles, and ensure the proper grade of oil is used.

Massive Oil Leak and Loss of Oil Pressure

The VVT-i oil line is known to burst. This is a very large leak which covers the ground, engine, and undercarriage.

If the oil line ruptures while driving, the low engine oil message and engine oil pressure warnings will illuminate. Continued use after these warnings will result in complete engine failure due to oil starvation.

The line is known to be defective, and a revised part has been issued by Toyota, however, this revised part is known for the same issue.

To repair the issue, the line must be replaced, and the engine bay and undercarriage must be cleaned thoroughly.

See More Problems (10)

2006 Toyota RAV4 Questions

how to know for sure it is the compressor when ac stops blowing cold? (1 answer)

ac quit blowing cold suddenly, had freon checked-full. what can i check or do to rule out other problems before buying an expensive compressor?

My 2006 Rav4 is hard to start, I changed the starter, changed mass air sensor (1 answer)

Car was running while in park, car died would not start back. (1 answer)

I was sitting in my car with it running (about 85 degrees outside) I looked and noticed that the lights on the dash were on but the air was still blowing. I turned the key to the off position and tried to re-start the car, it would turn the lights on the dash back on, my air was blowing, the rad...

See More Questions (58)

2006 Toyota RAV4 Recalls

Rear Suspension Arms Loosen And Fail

The rear tie rod adjusting lock nuts may not have been properly tightened after servicing. The rear arms may loosen and fail as a result. Dealers will replace both rear suspension arms and encapsulate the lock nuts free of charge to resolve the concern.

Seat Heater Wiring Shorts And Causes Fire

For vehicles equipped with aftermarket accessory seat heaters, the seat heater elements may short circuit when the seat cushion is compressed, and result in a fire hazard. Dealers will disconnect the seat heaters and refund the purchase price of the seat heaters free of charge to resolve the concern,

Rear Seat Belts May Fail During Frontal Collision

The seat belts in the rear on the outboard positions may get cut by the seat cushion frame during an accident. Dealers will install a bumper over both rear seat cushion frames free of charge to resolve the concern.

See More Recalls (11)

2006 Toyota RAV4 Reviews

Rated
based on 3 customer reviews
I had the same exact problem and i ended up paying for the whole repair which was $700. I'm so unhappy with Toyota. Now, at 86,000 miles, my engine mounts wore off and they misdiagnosed my car and made me pay for replacing the throttle which was $1100! They replaced my mounts and it fixed the idle problem but then now something is rattling in my car! They told me its normal wear and tear. And b...
2006 rav4 for past 2 years I been hearing a clunking noise from my steering wheel. The past 2 years toyota dealers kept saying they couldnt hear it or its not a big safety issue. I just found out few months ago that Toyota knows about the problem but will not do a recall because not enough people have complain and its not a safety issue. With all the bad publicity they have already you would th...
I was recently told my 2006 Toyota rav4 ABS brake pump should be replaced at the cost of $2100.00 just for the part plus labor of about the same cost. The pump has been leaking fluid. I wonder, had there been a recall on this model pump? LTD 2WD. ? George Moore

See More Reviews (3)
