2009 Toyota Matrix Repair and Maintenance
A guide to problems, costs, maintenance and repair for your 2009 Toyota Matrix
Never overpay. Check prices with our estimator
Verified by mechanics, reported by drivers like you
Ask a mechanic in our community
Our experts translate recalls into plain English
2009 Toyota Matrix ProblemsRough Running Conditions and Smoke From Exhaust
The head gasket may fail due to a defect in manufacturing of the cylinder block.
On this vehicle, the head bolts are known to pull the threads out of the engine block, allowing the head to slightly lift, and causing head gasket failure. Symptoms may include:
- White smoke from exhaust
- Rough running conditions and/or inability to start or idle
- White or cream colored oil on dipstick
- Check engine light
- OBD Trouble Codes P2181, P0300
When the head gasket fails, the bolt holes for the head bolts must be repaired before the cylinder head can be remounted.
This issue is not always preventable, but to help avoid it, never run the engine if the engine temperature is ever above the normal range.
Drivers of the Toyota Matrix may notice excessive oil consumption between oil changes, even to the extent of the engine oil warning light displayed on the multi-function display.
This issue is known to be caused by infrequent oil changes causing engine sludge, or worn piston rings.
The engine should be cleaned of oil sludge, and if oil consumption remains excessive, the engine may need new piston rings, or other internal components replaced.
To avoid this issue, change the engine oil and filter every 3,000 miles, and ensure the proper grade of oil is used.
The Check Engine Light may illuminate due to an evaporative emission (EVAP) system fault. Our technicians tell us these EVAP system faults can be difficult to diagnose but it is not uncommon to find a failed charcoal canister or a loose or worn gas cap.
2009 Toyota Matrix QuestionsWhy is the steering wheel shake when I am on highway? (1 answer)
If I go over 70mph.
It happens when I step on the brake all the way.
The emission control is "not ready" for inspection. There is no "check engine light" indicating something is wrong. I was told the car was not driven enough after battery died.
2009 Toyota Matrix RecallsPassenger Frontal Air Bag Inflator Ruptures On Deployment
The passenger frontal air bag inflator may rupture on deployment, causing metal fragments to come through the air bag and injure occupants. Dealers will replace the passenger frontal air bag inflator or in some cases replace the air bag assembly free of charge to resolve the concern.
The driver's side power window master switch may lack enough proper lubricant to protect the sliding electrical contacts of the switch. This can cause a short circuit of the switch, leading to overheating and melting of the switch. Dealers will inspect the switches and apply lubricant to them if no abnormality is found. If a problem is found, the switch circuit board will be replaced. These inspections and repairs will be performed free of charge to resolve the concern.
The steering column assembly contains electrical connections for the driver's airbag, commonly called the "clock spring". This spiral cable assembly includes a Flexible Flat Cable (FFC). Due to the shape and location of the FFC's retainer, the FFC could become damaged when the steering wheel is turned. If the FFC is damaged, the driver's airbag could be deactivated. The failure of the driver's airbag to deploy when required increases the risk of injury to the driver. When the parts are available, dealers will replace the spiral cable assembly to correct this concern.
