2009 Toyota 4Runner Problems

Car Won't Start Due to Worn/Corroded Solenoid Contacts in Starter

If the car will not start, the most likely problem is worn or corroded solenoid contacts in the starter. Usually, these parts can be replaced without purchasing a new starter.

Check Engine Light Due to Failed Charcoal Canister

The evaporative emission (EVAP) system may illuminate the vehicle's Check Engine Light due to intermittent failure of the charcoal canister purge control solenoid valve or canister failure. Upon failure of the charcoal canister, debris may circulate around the EVAP system causing other emission control problems.

Loud Vacuum Cleaner Noise on Cold Start

Drivers may hear a loud noise, much like a vacuum cleaner, coming from their engine on cold starts. This affects the 2005-2009 Toyota 4Runner V8 models.

The noise is from the secondary air pump, which sends hot air to the catalytic converter when the engine is cold. This allows the catalytic converter to clean exhaust better, and lower emissions while the engine is warming up.

Pump failure may result in:

Fixing the issue involves removal of the intake manifold, and replacement of the secondary air pump.

See More Problems (3)

2009 Toyota 4Runner Recalls

Seat Heater Wiring Shorts And Causes Fire

For vehicles equipped with aftermarket accessory seat heaters, the seat heater elements may short circuit when the seat cushion is compressed, and result in a fire hazard. Dealers will disconnect the seat heaters and refund the purchase price of the seat heaters free of charge to resolve the concern,

Seat Heater

Southeast Toyota is recalling certain vehicles because the seat heater element may become damaged as a result of compression of the seat cushion. The damaged element could short causing burning of the seat cushion, increasing the risk of personal injury. Dealers will disconnect seat heaters with copper strand elements and refund the purchase price of the seat heater accessory to correct this concern.

Vehicles With Added Seat Accessories May Not Have Properly Functioning Restraint Systems

Vehicles that have had accessories added to the seats such as seat heaters, seat covers or DVD headrests may not have the occupant sensor system of the passenger seat calibrated properly. This can affect passenger air bag operation in a crash. Dealers will test the sensitivity of the occupant detection sensors and recalibrate them as necessary free of charge to resolve the concern.

See More Recalls (6)
