2005 Mercedes-Benz E320 Repair and Maintenance

A guide to problems, costs, maintenance and repair for your 2005 Mercedes-Benz E320

No_car_image
Get a Repair Estimate
Guaranteed by certified locations nationwide. Learn more
Get a Repair Estimate For Your 2005 Mercedes-Benz E320
RepairPal estimates are guaranteed at over 1,700 quality certified locations nationwide. Learn more
Repair Estimates

Never overpay. Check prices with our estimator

2005 Mercedes-Benz E320
$
231
to $
696
2005 Mercedes-Benz E320
$
340
to $
1,694
2005 Mercedes-Benz E320
$
165
to $
340
2005 Mercedes-Benz E320
$
363
to $
798
2005 Mercedes-Benz E320
$
128
to $
295

2005 Mercedes-Benz E320 Problems

"Crank no Start" Due to Failed Crankshaft Position Sensor

The crankshaft position sensor may fail. Symptoms of this are: The engine will crank—but not start—especially when the engine is warm. The car may start again if it is left to cool off, but it may run roughly or have poor performance.

Engine Oil Leak From PCV Vent Housing and/or Engine Inspection Plate

An engine Oil leak may develop from the PCV vent housing on the valve cover and/or the inspection plate on the front of the engine.

Oil Seepage on Back of the Cylinder Heads

Mercedes Benz E320 models manufactured between 2005 and 2009 may have engine oil seeping or leaking from the back of the cylinder heads. This is commonly misdiagnosed as leaking valve covers.

On the back of the cylinder heads there are three, in total, plastic expansion plugs that plug access ports to the camshafts. These plugs are well known for seeping oil, and leaking if left unattended. The oil will run down the back of the engine and eventually make it to the ground.

Replacement of these three plastic plugs is extremely simple, and should be done as regular maintenance. The recommended interval for replacement is every 60,000 miles.

See More Problems (26)

2005 Mercedes-Benz E320 Questions

Electrical issue w/ Instrument cluster, turn signals, and minor electricals (1 answer)

My turn signals will not operate at all. The physical lights work fine when I turn the running lights on. But when I signal left, right, or use the hazards absolutely nothing happens. Also the fuel level doesn't read. Everything else works on the cluster including the menus. It does say on th...

I have a picture of a battery. What does this mean (1 answer)

I have a message with a picture of a battery. what does this mean? (1 answer)

See More Questions (24)

2005 Mercedes-Benz E320 Recalls

Incorrect Software Calibration May Cause Fuel Pump to Remain Powered in a Collision

There is a faulty software calibration that affects several areas including shutting off the fuel supply in a collision. This could cause a fire hazard during an accident. Dealers will reprogram this software. The Mercedes-Benz recall number is 2008 070001. This recall began during August, 2008.

Sensotronic Brake Control System May Default to Basic Hydraulic Mode

Due to deterioration of the wiring harness connection or failure of the hydraulic pump, the sensotronic brake control (SBC) system may default to the hydraulic back-up mode. In the back-up mode, the driver has braking power sufficient to stop the vehicle, but greater brake pedal pressure is required and brake pedal travel will be noticeably longer. Dealers will install a bracket and replacement ground wire to the SBC pump unit on all affected vehicles. Additionally, dealers will inspect and replace the SSC pump unit in certain SL models. The Mercedes-Benz recall numbers are 2005070007 AND 2005110001.



The Sensotronic Brake System May Be Disabaled

High mileage combined with a high number of brake actuations, or a high brake actuation frequency, can cause the pump motor of the SBC to run out of permissible tolerances. As a result, excessively high pressure may build the high pressure line of the brake system. If this occurs, the system will switch into the hydraulic function mode as designed. Sensotronic brake control is disabled when the brake system is functioning in the hydraulic mode. Dealers will inspect the SBC hydraulic unit and replace it if necessary to correct this concern. The Mercedes-Benz recall number is 2004 050014.

See More Recalls (3)

2005 Mercedes-Benz E320 Reviews

Rated
based on 2 customer reviews
This car is built to a high quality standard. The only problem with the E320 is that sometimes it feels underpowered for the weight of the car and the suspension is a little mushy, but that is also what gives this car such it's smooth ride. The larger E430 does allow the car to move a little quicker, but once your up to speed you can't beat the gas mileage of the smaller engine. Overall this ca...
Best car on the road bar none.

See More Reviews (2)
