Resources for the Repair and Maintenance of your 1994 Mazda B2300

1994 Mazda B2300

Image for car images Mazda 1994 1997 Mazda B2300 size thumb

1994 Mazda B2300 Problems

Engine -- Verified

If the engine cranks but does not start, it may be caused by a tripped inertia switch. Switch the key to "ON" and the fuel pump should be heard running for a second or two. Listen at the gas filler if necessary. The inertia switch is located on the firewall and can be tripped when the parking brake is set too hard and then released. The inertia switch should be reset, and will click when it is reset.

Engine -- Verified

The engine may fail to start due to an electrically shorted sensor. Some of the sensors may internally short and not blow any fuses. A technician may find no spark and no operation of the fuel injectors in the diagnosis. One way a technician may isolate the defective sensor is by disconnecting sensors one by one to see if the engine starts.

Engine -- Verified

Water intrusion into a connector (X309) located under the cab, beneath the driver's seat, can cause a rough idle, ABS Light and Check Engine Light illumination, and automatic transmission shifting problems. If needed, connector repair parts are available from Mazda dealers, and possibly some Ford dealers.

Engine -- Verified

A dirty, or contaminated mass airflow (MAF) sensor can cause the engine to run poorly. There may be a Check Engine Light with trouble codes relating to the MAF sensor. In some cases, carefully cleaning the sensor element will fix the problem, but replacement may be required.

Engine -- Verified

The Check Engine Light may come on with a trouble code for the Cam Position Sensor (CMP), P0340. This can be caused by the negative battery cable being too close to the sensor. The cable should be repositioned, clear the trouble code, and verify that the cable is causing the problem.

1994 Mazda B2300 Recalls (Recent)

Brakes, November 4, 1994

Summary: THE PARKING BRAKE CONTROL SELF-ADJUST PAWL DOES NOT LINE UP PROPERLY WITH THE SELF-ADJUST RACHET CAUSING THE PAWL TO SLIP OVER ONE OR MORE TEETH IN THE RACHET.

Learn more »

Brakes, May 21, 1996

Summary: THE STUDS WHICH ATTACH THE BRAKE MASTER CYLINDER TO THE POWER BRAKE VACUUM BOOSTER ASSEMBLY CAN DEVELOP STRESS CORROSION CRACKING AFTER BEING OPERATED FOR AN EXTENDED PERIOD OF TIME IN THE SOUTHERN CALIFORNIA LOCATION.

Learn more »

Drive Train, August 26, 2000

RepairPal Expert Overview:

Ford has recalled Firestone Wilderness AT and Radial ATX tires installed on multiple lines of Ford trucks from 1991 to 2000. On some tires, under extreme conditions, the tread could separate, which can cause immediate tire failure. This may lead to a loss of vehicle control, injury, and death. Dealers replaced the affected tires.

Learn more »

Drive Train, April 12, 1996

Summary: DURING EXTREME COLD, NORTHERN CLIMATE WINTER CONDITIONS, ICE CAN FORM IN THE THROTTLE BODY OF THE ENGINE CAUSING THE THROTTLE PLATE TO REMAIN IN THE HIGHWAY CRUISING POSITION AFTER THE ACCELERATOR IS RELEASED OR THE SPEED CONTROL IS DEACTIVATED.

Learn more »

Engine, July 5, 1994

Summary: THE FRONT FUEL LINES HAVE A SECTION OF FLEXIBLE HOSE THAT IS SUSCEPTIBLE TO CRACKING WHICH CAN ALLOW FUEL LEAKAGE.

Learn more »

1994 Mazda B2300 Questions and Answers

johnwayne, 1994 Mazda B2300, Berry, KY

How come I still don't have pressure after replacing master,slave cylinder? I have bled 2 quarts of brake fluid through the system and still don't have pressure. I do have suction at the ...

jaunalso, 1994 Mazda B2300, Gastonia, NC

Which sensor regulates the fuel/air mix and how much does it cost?

jaunalso, 1994 Mazda B2300, Gastonia, NC

The engine won't start sometimes. The motor turns over very fast but won't crank. This happens more often if it is turned off and tried to crank up to 5 minutes afret being turned off.

jaunalso, 1994 Mazda B2300, Gastonia, NC

My truck has been getting very bad gas milage. I have tried injection cleaners and a tune up. The truck is getting 13 miles per gallon; that is not good for that kind of truck. I have had it dianos...

jaunalso, 1994 Mazda B2300, Gastonia, NC

Which sensor/part acts as the points, as in an older car? Sometimes the motor won't start. It seems like the points need changed but there are no points. After a few minutes of not trying to c...

Write a Review About Your Car

1994 Mazda B2300 Reviews

I have really enjoyed this truck. It is a steal for the money, and it is super reliable, easy to work on, and generally cheap to fix. Steering constantly feels loose (even after new steering box), but hey, it's a truck from '94. Also, the truck feels very light and floaty sometimes, but again, that is what I expected out of this lightweight truck. Great gas mileage, even with bigger tires installed! (235/75/15)

I must agree with everyone...it's the best vehicle i have ever had and i have kept it the longest...its a 94 and I'm pretty sure it still has the same clutch assembly...which would probably be the reason I am having to change it out...am tryin to find instructions on how to do it and what tools i will need...if you have any help facebook me Garion Brooks or email me garion_r_brooks@yahoo.com
