2009 BMW 535i ProblemsOutside Mirror May Fold Out To Far
One vehicles equipped with power folding mirrors, the mirror may fold out past the standard position. Our technicians tell us that if this occurs a special procedure must be followed to relearn the correct mirror home position.
Late model BMW 535i turbo engines suffer from waste gate issues which become progressively worse with normal driving and especially with harsh driving conditions.
The turbocharger uses exhaust gas to create air pressure which is then forced into the engine. When there is no demand for power, the exhaust gases are released into the exhaust through a waste gate to prevent the turbo from speeding up.
“Waste gate rattle” or “Turbo rattle” is a result of excessive movement between the waste gate and the waste gate seat. This is a progressive issue with the following symptoms:
- Rattling at cold start
- Rattling upon deceleration
- Loss of power
- Check Engine Light Illumination
- Manufacturer Specific OBD trouble code P30FF
- Very poor engine performance and MPG
Adjustment of the waste gate actuator can solve the issue, but the issue will return. If adjustment does not correct the issue, the turbocharger waste gate must be rebuilt with new bushings, or the turbocharger must be replaced. BMW has replaced many turbocharger assemblies under warranty to correct this issue.
2009 BMW 535i Questionsat what mile should i have spark plugs change, 58,400 miles on currently (1 answer)
is it safe to wait til 75,000 miles or up to 100,000
I have taken the vehicle to BMW three times for this same reason. They have charge me for a oil diagnostic 190.00. The problem still exist. I took the car back yesterday and show them where the leak is located in the oil housing area. They saw it this time and said that it was ok, charge me an...
2009 BMW 535i RecallsExterior Lighting Concern
Increased resistance at the electrical contact points may cause damage to the ground terminal and housing of the connector. This can result in an intermittent or permanent loss of one or more rear lamp functions (tail, brake, turn-signal, reverse). Intermittent light operation reduces the ability to warn other motorists of the driver's intentions, increasing the risk of a crash. Dealers will replace the rear lamp bulb carriers to correct this concern.
The insulated connector for the positive battery cable may have been incorrectly attached to the trunk floor panel, which can lead to a loosening of the bolt connection. Loosening of the connection can cause an increase in electrical resistance and overheating of the cable connection, which could lead to a fire, even when the vehicle is not in use. As a precaution, owners are advised to park outside until the remedy has been completed. Dealers will secure the battery bolt cable connection as necessary to correct this concern.
The brake system vacuum pump check valve can leak oil and contaminate the power brake booster. This can result in loss of power brake assist. Dealers will repair the vehicle as necessary free of charge to resolve concerns.
