2010 BMW 135i Repair and Maintenance

A guide to problems, costs, maintenance and repair for your 2010 BMW 135i

2010 BMW 135i Problems

Outside Mirror May Fold Out to Far

One vehicles equipped with power folding mirrors, the mirror may fold out past the standard position. Our technicians tell us that if this occurs a special procedure must be followed to relearn the correct mirror home position.

Check Engine Light with Code P30FF and Rattle from Engine

Late model BMW 135i turbo engines suffer from waste gate issues which become progressively worse with normal driving and especially with harsh driving conditions.

The turbocharger uses exhaust gas to create air pressure which is then forced into the engine. When there is no demand for power, the exhaust gases are released into the exhaust through a waste gate to prevent the turbo from speeding up.

“Waste gate rattle” or “Turbo rattle” is a result of excessive movement between the waste gate and the waste gate seat. This is a progressive issue with the following symptoms:

  • Rattling at cold start
  • Rattling upon deceleration
  • Loss of power
  • Check Engine Light Illumination
  • Manufacturer Specific OBD trouble code P30FF
  • Very poor engine performance and MPG

Adjustment of the waste gate actuator can solve the issue, but the issue will return. If adjustment does not correct the issue, the turbocharger waste gate must be rebuilt with new bushings, or the turbocharger must be replaced. BMW has replaced many turbocharger assemblies under warranty to correct this issue.

Noise and/or Vibration Due to AC System Low on Refrigerant

A droning type noise may be noted when the air conditioning system is operating. Additionally, a vibration may be felt in the steering wheel. If these issues are no longer present when the AC system is turned off, the problem may be low refrigerant charge in the system. Our technicians remind us that if the refrigerant charge is found to be low, proper leak diagnoses should be performed in addition to recharging the AC system.

See More Problems (3)

2010 BMW 135i Recalls

Driver's Frontal Air Bag Inflator Ruptures And Sprays Metal Fragments

The driver's frontal air bag inflator may deploy the air bag with excessive pressure, resulting in the inflator rupturing and causing metal debris to be sprayed onto vehicle occupants. Dealers will replace the driver's frontal air bag free of charge to resolve the concern.

The Battery Cable Connection at the Fuse Block May Break

The vehicle battery is connected to the fuse box via a heavy duty cable. It has been determined that the cable connection at the fuse box can degrade over time, resulting in increased electrical resistance. This increased resistance can cause the connection point to overheat and break, resulting in a loss of electrical power and causing the engine to stall, increasing the risk of a crash. Dealers will replace the positive battery cable connector and secure it with an improved method to correct this concern.

Sound Insulation Around Seat Belt Buckles Could Ignite in a Collision

The seat belt pretensioner explosion that occurs during a collision may ignite the sound insulation around the buckles. Dealers will modify the sound insulation on all vehicles, and relplace the seat belt on some models. This recall began on August 23, 2010.



See More Recalls (3)
